H200 Hydraulic Rock Drill

The H200 hydraulic rock drill is designed for rock bolting on rock support rigs, suitable for tunneling and mine development drilling.

MAIN DIMENSIONS
Hole diameter bolting	33 - 41 mm
Hole diameter drilling	35 - 41 mm
Hole diameter reaming	76 - 89 mm
Power class	10 kW
Percussion rate	40 - 65 Hz
Operating pressure percussion rotation (max.)	140 - 200 bar, 210 bar
Rotation motor type	OMS 125
Drill steels bolting (drilling), Drifting	Male R32 - Male R25 Male R28 - Male R32 Male R32 - Male R38
Shanks Bolting (TUC drilling line) Bolting (TUC bolting line for S bolting system) Drilling	R32 (female) R32 (male) - R38 (male) R32 (male) - R38 (male)
Weight	95 Kg
ROTATION MECHANISM
Motor	Orbit type
Motor type 1	OMS 125
Torque (at 175 bar)	420 Nm
Rotation speed	0 - 300 rpm
Flow (at max speed)	40 l/Min
FLUSHING PRESSURE
Max. pressure (air / water)	15 bar
ACCUMULATORS
Accumulator gas	Nitrogen N2
High pressure (HP)	55 bar
Filling valve	Vg8 DIN7756
SHANK LUBRICATION
Air flow	250 l/min
Pressure	2.5 bar
Oil consumption	100 g/h
OIL RECOMMENDATION
Oil operating temperature	+40°C up to +65°C
Oil recommendation	See Sandvik drill rigs lubricant recommendation for detailed information
OPTION
Special tools for H200 Complete set	ID 7834 0065
Flushing head	+ 20 kg
